Carverall Z5 Dual Laser Engraver

Regular price $989.00 USD
Regular price $1,499.00 USD Sale price $989.00 USD
-$510.00 USD
Shipping calculated at checkout.
Return & Refund Policy

Free shipping and Tariffs

30-Day Return & Exchange | 12-Month Warranty

24-hour Customer Service

Guaranteed Safe Checkout

fb92c42d-16a9-4684-85e4-c962e3b01b5c_1b9642d5-ac42-447b-a4aa-aedc28f0016e - Carverall
Brand: Carverall
Availability: Low stock: 5 left
SKU: CAZ5
Regular price $989.00 USD
Regular price $1,499.00 USD Sale price $989.00 USD

Choose the Right Z5 for Your Work

Choose precision metal marking with the single-light-source model or expand your applications with the dual-light-source configuration.

Precision Marking

Z5 Single Light Source

Equipped with a 2W 1064nm infrared laser for high-precision marking on metals, selected plastics and other compatible materials.

  • 2W 1064nm infrared laser
  • High-precision metal and plastic marking
  • Dual red-light manual focusing
  • Windows software connection
  • Ideal for tools, jewelry and precision parts
Feature Z5 Single Light Source Z5 Dual Light Source
Laser Configuration 2W 1064nm infrared laser 2W 1064nm infrared laser + 5W 455nm blue diode laser
Core Function High-precision metal and plastic marking Metal marking, non-metal engraving and cutting
Metal Processing Marks metal, coated metal, anodized aluminum and selected plastics Uses the 2W infrared laser for precision metal and plastic marking
Non-Metal Processing Limited compatibility depending on material absorption Uses the 5W blue laser for wood, leather, paper, fabric and selected acrylic
Cutting Capability Not designed for material cutting Cuts selected thin wood, leather, paper, fabric and dark acrylic
Focusing Method Dual red-light manual focus Auto focus with adjustable focusing bracket
Positioning Dual red-light preview for accurate positioning Fast positioning and preview for both laser sources
Laser Head 180° rotatable for large or irregular objects 180° rotatable for flexible engraving placement
Connectivity Windows software connection Bluetooth; supports Android, iOS, Windows and macOS
Safety Protection Safety system helps stop laser output when accidental contact is detected Automatic laser shut-off when abnormal tilting or shaking is detected
Recommended For Users focused on professional metal marking and precision engraving Creators who work with both metal and non-metal materials

Swipe left or right to view the full comparison.

Two Laser Sources in One Machine

The Z5 Dual Light Source integrates infrared and blue diode laser technologies, allowing you to switch laser sources according to the material.

2W · 1064nm

Infrared Laser

Designed for precise marking on stainless steel, aluminum, coated metal, jewelry, electronic components, hard plastic and other compatible industrial materials.

5W · 455nm

Blue Diode Laser

Designed for engraving and cutting selected non-metal materials, including wood, leather, paper, fabric, cardboard and dark acrylic.

Compact Design, Flexible Creation

Explore the Z5 design, positioning system, compatible materials and practical engraving applications.

Carverall Z5 compact portable laser engraver design Carverall Z5 laser engraver features and operating design Z5 infrared laser engraving on compatible plastic materials Z5 infrared laser marking on metal materials Carverall Z5 laser engraving demonstration Carverall Z5 portable engraving application Carverall Z5 laser engraver product details

Z5 Technical Specifications

Compare the single-light-source and dual-light-source configurations.

Carverall Z5 portable dual-light-source laser engraver

Portable Multi-Material Laser Engraver

The Z5 combines a compact aluminum body, 180-degree rotatable laser head and flexible operating design. The dual-light-source version expands its capabilities by integrating both infrared and blue diode laser technologies into one machine.

2W + 5W Dual laser configuration
70 × 70mm Engraving area
Up to 800mm/s Engraving speed
180° Rotation Flexible laser head
Specification Single Light Source Dual Light Source
Laser Sources One infrared laser source Infrared laser + blue diode laser
Laser Power 2W infrared 2W infrared + 5W blue diode
Laser Wavelength 1064nm 1064nm + 455nm
Total Power <200W <200W
Body Material High-strength anodized aluminum High-strength anodized aluminum
Focusing Method Dual red-light manual focus Auto focus
Connectivity Windows software connection Bluetooth; Android, iOS, Windows and macOS
Power Supply 12V / 10A DC 12V / 10A DC
Cooling Method Air cooling Air cooling
Engraving Area 70 × 70mm 70 × 70mm
Infrared Accuracy ≤0.01mm ≤0.01mm
Blue Laser Accuracy Not applicable 0.05mm
Maximum Speed 800mm/s 800mm/s
Product Dimensions 286 × 190 × 313mm 286 × 190 × 313mm
Product Weight 5.7kg 5.7kg

Swipe left or right to view all specifications.

Compatible Materials

Select the appropriate laser source according to the material and processing requirement.

2W INFRARED

Metal and Plastic Marking

Suitable for stainless steel, aluminum, coated metal, anodized aluminum, gold, silver, copper, titanium, hard plastic, PVC, electronic components and other compatible materials.

5W BLUE DIODE

Non-Metal Engraving and Cutting

Suitable for engraving wood, bamboo, leather, paper, fabric, cardboard, selected acrylic, ceramic and coated surfaces. It can also cut selected thin wood, leather, paper, fabric and dark acrylic.

Material notice: Actual results depend on material composition, color, thickness, focus and processing parameters. Always run a small material test before production. Transparent, white and some light-colored acrylic materials may not absorb the 455nm blue laser effectively.
